| Name: | 600V TTU cable single CU/AL conductor XLPE insulation PVC jacket |
| Inquiry |
Product Description
CABLE TTU
SPECIFICATIONS
These cables are manufactured according to COVENIN 541 standard, copper conductors type B3, B8, ASTM
APPLICATIONS
Low voltage generation and distribution circuits, in industries, shops, transformation chambers and power generation plants.
JACKET
XLPE - 90°C PVC. Resistant to humidity, does not propagate flame.
VOLTAGE: 600V 2000V
TEMPERATURE 90°C
<td width="68" valign="top" style="padding: 0px; border-left-width: 2px; border-left-color: rgb(0, 0, 0); border-right-width: 2px; border-right-color: rgb(0, 0, 0); border-top:
CONDUCTOR |
ESPESOR DE AISLAMIENTO |
DIÁMETRO SOBRE AISLAMIENTO |
ESPESOR CHAQUETA |
DIÁMETRO EXTERIOR APROX |
PESO TOTAL APROX | CAPACIDAD DE CONDUCCIÓN | |||||
CALIBRE | NÚMERO DE HILOS | SECCIÓN APROX | DIÁMETRO APROX | PESO APROX | (1) | (2) | |||||
AWG O MCM | mm2 | mm | kg/km | mm | mm | mm | mm | kg/km | A | A | |
8 | 7 | 8,37 | 3,70 | 75,90 | 1,40 | 5,98 | 0,38 | 6,74 | 105,33 | 50 | 70 |
6 | 7 | 13,30 | 4,65 | 120,60 | 1,40 | 7,45 | 0,76 | 8,97 | 176,73 | 65 | 95 |
4 | 7 | 21,12 | 5,88 | 191,51 | 1,40 | 8,68 | 0,76 | 10,20 | 257,61 | 85 | 125 |
2 | 7 | 33,54 | 7,41 | 304,13 | 1,40 | 10,21 | 0,76 | 11,73 | 382,63 | 115 | 170 |
1/0 | 19 | 53,52 | 9,45 | 485,31 | 1,65 | 12,75 | 1,14 | 15,03 | 613,68 | 150 | 230 |
2/0 | 19 | 67,35 | 10,65 | 610,72 | 1,65 | 13,95 | 1,14 | 16,23 | 751,48 | 175 | 265 |
3/0 | 19 | 84,91 | 11,95 | 769,95 | 1,65 | 15,25 | 1,14 | 17,53 | 924,24 | 200 | 310 |
4/0 | 19 | 107,41 | 13,40 | 973,97 | 1,65 | 16,70 | 1,14 | 18,98 | 1143,12 | 230 | 360 |
250 | 37 | 126,37 | 14,55 | 1157,13 | 1,90 | 18,35 | 1,65 | 21,65 | 1399,94 | 255 | 405 |
300 | 37 | 151,85 | 15,95 | 1390,44 | 1,90 | 19,75 | 1,65 | 23,05 | 1651,75 | 285 | 445 |
